436-6210 20R-7974 548-9082 540-6526 A400/A4000 Monitor for CAT 320E 336E 349E

Product Overview

New aftermarket A400/A4000 operator monitor for select Caterpillar D2, E and F-series excavators, wheeled excavators, material handlers and forestry equipment.

This listing includes one programmed monitor. The reference numbers identify possible monitor applications and do not indicate the package quantity.

Programming is included after the original part number, machine information and physical configuration have been verified.

Reference Part Numbers

• 436-6210
• 20R-7974
• 548-9082
• 540-6526

436-6210 is associated with an operator monitor configuration using 6-pin and 12-pin connectors. 20R-7974 is a remanufactured reference associated with 436-6210. The product supplied by XAVORNIK is a new aftermarket replacement and is not a genuine Cat or Cat Reman product.

548-9082 is associated with an A4000 controller operator monitor. 540-6526 is an earlier A400 control-group reference. These part numbers may represent different production dates, software configurations or machine arrangements.

Do not assume that all four reference numbers are interchangeable on every listed machine.

Reference Applications

Additional Equipment Applications

Depending on the original monitor number and machine configuration, reference coverage may also include selected M314F, M316F, M318F, M320F, M322F and M323F wheeled excavators; MH3022, MH3024 and MH3026 material handlers; and 538, 548, 558, 568 FM and 568 FM LL forestry equipment.

Important: The application information combines the reference coverage of the individual part numbers. It does not mean that every listed reference number fits every machine or serial-number range.

Fitment Verification Required

Please provide the following information before ordering:

• Original monitor part number
• Complete machine model, including suffixes
• Machine serial number or PIN
• Engine serial number, if available
• Clear photo of the complete front display and button layout
• Clear photo of the rear housing and identification label
• Clear photos of all connectors and connector pins
• Clear photo of the mounting bracket and mounting points

The front-panel layout, rear housing, mounting points, connector quantity, 6-pin and 12-pin connector arrangement, connector keying and pin configuration must match the original monitor.

Programming

The listed price includes programming based on the verified machine information supplied by the customer. Programming begins only after the original part number, machine PIN, connector configuration and required software information have been reviewed.

Estimated processing time is 2–3 business days after all fitment and programming information has been verified. Incorrect or incomplete machine information may delay processing or result in an incompatible configuration.

Package Includes

• 1 × New aftermarket A400/A4000 operator monitor
• Programming based on verified machine information

Not Included

• Wiring harness
• Mounting bracket or mounting hardware
• Camera or video cable
• Sensors or external control modules
• Installation labor

Installation Requirements

Professional installation and electrical-system inspection are strongly recommended. Before connecting the replacement monitor, inspect the machine voltage, power supply, grounds, wiring harness, connector terminals and related control modules.

Do not install the monitor when the machine has bent pins, loose terminals, damaged connectors, incorrect voltage, reversed polarity, water-damaged wiring or an unresolved short circuit. External electrical faults may immediately damage the replacement monitor.

Warranty

12-Month Limited Warranty

The warranty covers confirmed manufacturing defects under normal use. Damage caused by incorrect fitment information, improper installation, short circuits, incorrect voltage, damaged connectors or wiring, external electrical faults, unauthorized disassembly, water ingress, impact or modification is not covered.

This monitor is programmed specifically for the verified machine information supplied by the customer. Damage or incompatibility caused by incorrect or incomplete machine information is not covered.

Returns and warranty claims are subject to the XAVORNIK Returns & Refund Policy.

Trademark Notice

XAVORNIK is not affiliated with Caterpillar Inc. Caterpillar, Cat and the referenced machine model names are used only to identify product compatibility.
